Built for Pressure, Designed for Precision | Reliable 20mm Mechanical Shaft Seal For Chemical Pump
The Reliable 20mm Mechanical Shaft Seal For Chemical Pump is engineered for high-performance fluid sealing in corrosive and chemical-intensive environments. This precision-designed shaft seal is built with chemical-resistant materials like carbon, ceramic, Viton, and stainless steel to ensure long-lasting durability and resistance against aggressive media. Whether in chemical manufacturing, pharmaceutical processing, or wastewater treatment plants, this 20mm mechanical seal delivers optimal face contact, prevents leaks, and withstands thermal shock and pressure fluctuations. Its compact form and standard sizing make it an ideal fit for most chemical pumps, reducing maintenance downtime while maximizing operational efficiency.
Its advanced design not only enhances sealing efficiency but also minimizes energy loss and pump wear, making it a cost-effective solution for continuous operation in critical chemical applications. The dynamic balance between the rotating and stationary faces ensures smooth performance under varying speeds and pressures. Additionally, the seal’s compatibility with a wide range of chemical fluids and pump models makes it a versatile choice for both OEM installations and maintenance replacements. Built for rugged environments and engineered to exceed industry standards, this 20mm mechanical shaft seal is a dependable asset in any chemical processing setup.
Product Specifications
| Attribute | Specification |
|---|---|
| Product Name | Reliable 20mm Mechanical Shaft Seal For Chemical Pump |
| Standard or Nonstandard | Standard |
| Rotary Ring | SIC\TC |
| Stationary Ring | SIC\TC |
| Secondary Seal | FKM |
| Temperature Range | -20℃ ~ 180℃ |
| Sample | Yes (US$20) |
| Color | Silver |
| Size | 20 mm |
| Pressure Rating | Up to 1.2 MPa |
| Speed Limit | ≤15 m/s |
| Application | Industrial Pumps |
| Material Grade | Corrosion & Wear Resistant |
| Seal Type | Balanced |
| Mounting Type | Cartridge / Component |
| Spring Type | Single Spring |
| Media Compatibility | Water, Oil, Chemicals |
Why Choose Reliable 20mm Mechanical Shaft Seal For Chemical Pump?
🔹 Engineered for use in corrosive and chemically aggressive environments
🔹 Precision-balanced for smooth operation at varying pressures and temperatures
🔹 Constructed with high-performance Viton, ceramic, and stainless steel materials
🔹 Compact 20mm size suits a wide range of chemical pump systems
🔹 Ensures leak-free sealing, reducing downtime and contamination risk
🔹 Highly resistant to thermal distortion and abrasive media
🔹 Quick and easy to install in OEM and replacement scenarios
🔹 Compatible with standard chemical pump configurations
🔹 Backed by strict quality control and performance testing
🔹 Enhances pump life and reduces mechanical wear
Application of Reliable 20mm Mechanical Shaft Seal For Chemical Pump
🔹 Chemical Processing Plants – Designed for pumps handling acids, alkalis, and solvents
🔹 Pharmaceutical Production – Maintains clean sealing in sensitive environments
🔹 Food & Beverage Industry – Used where sanitary-grade sealing is required
🔹 Wastewater Treatment – Withstands corrosive and particulate-laden fluids
🔹 Petrochemical Facilities – Performs reliably in hydrocarbon and oil-based operations
🔹 Industrial Manufacturing – Seals fluid systems in paint, coatings, and plastics production
🔹 OEM Use – Ideal for new chemical pump system builds
🔹 Maintenance and Repair – Trusted replacement part for routine maintenance
Order Now – Get Your Reliable 20mm Mechanical Shaft Seal For Chemical Pump Today!
Secure your operations with the Reliable 20mm Mechanical Shaft Seal For Chemical Pump, built to withstand the harshest chemical conditions. Designed for long-term durability and dependable sealing, this seal enhances pump efficiency while minimizing fluid loss and equipment wear. Whether you’re replacing worn components or outfitting new systems, this seal offers an affordable, high-quality solution backed by industry-leading materials. Elevate your pump performance with a sealing solution that prioritizes precision, protection, and performance under pressure.
